Tanvir Nickel Alloys is a trusted manufacturer and supplier of high-quality Titanium Gr 11 Pipes in Cairo, Egypt. Known for their exceptional strength and corrosion resistance, these pipes are ideal for demanding applications across aerospace, marine, and chemical industries. Composed of Titanium, Aluminum, Vanadium, and Palladium, Titanium Gr 11 Pipes offer excellent fatigue resistance and the ability to perform in high-temperature and high-pressure environments. Whether used in critical aerospace components, seawater desalination systems, or chemical processing, these pipes deliver unmatched durability and reliability. We provide custom solutions tailored to meet the specific requirements of each industry, ensuring superior performance.
Titanium Grade 11 Pipes are top-notch pipes made from commercially pure titanium (CP-Ti Grade 2, annealed to meet Grade 11 standards). They’re designed to offer outstanding corrosion resistance, strength, and durability, especially in tough industrial settings. These pipes are crafted with precision to ensure they have a consistent wall thickness, a smooth surface finish, and excellent dimensional accuracy. This makes them perfect for piping systems that come into contact with harsh chemicals, seawater, and high temperatures. With the lightweight nature of titanium and its remarkable mechanical integrity, these pipes promise long-lasting reliability and require minimal maintenance, which is why they’re a go-to choice in industries like chemical processing, marine applications, desalination, and power generation.
| Standards : | ASTM B862, B861 / ASME SB862, SB861 |
| Dimensional : | ANSI/ASME X6.19M, ANSI/ASME X6.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Grade 11 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.163 lb/in3 | 1668 °C | Psi – 39900 , MPa – 275 | Psi – 59500 , MPa – 410 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 11 | 3.7195 | R56320 |
When it comes to composition, Titanium Grade 11 Pipes are primarily made of commercially pure titanium, featuring low levels of interstitial elements like oxygen, nitrogen, and iron. This combination boosts their mechanical properties while keeping corrosion resistance at a high level. They stand out for their exceptional resistance to chloride-induced corrosion, seawater, and acidic environments. With high tensile strength, great ductility, and superior resistance to fatigue and creep, they’re well-suited for high-pressure and high-temperature piping systems. The low density of titanium, paired with its impressive toughness, ensures these pipes maintain their structural integrity and dimensional stability, even in demanding operating conditions.
Contact us to get a quick quote for your requirement.
You’ll find Titanium Grade 11 Pipes widely used in chemical processing plants, desalination facilities, offshore oil and gas platforms, marine applications, and power generation sites. They excel at transporting aggressive fluids, seawater, acids, and high-purity water, where corrosion resistance and longevity are essential. Common uses include heat exchangers, piping networks, process vessels, and condenser tubes. Their durability, lightweight nature, and excellent resistance to scaling and fouling make them a preferred option in critical environments, ensuring safe and efficient operations.
