Tanvir Nickel Alloys, located in Cairo, Egypt, stands out as a top-notch manufacturer and supplier of high-quality Monel Sheets and Plates, celebrated for their remarkable durability and quality. With years of expertise in the nickel alloy sector, the company guarantees that every product adheres to international standards, providing exceptional corrosion resistance, impressive strength, and outstanding performance even in extreme conditions. Industries across the board trust Monel Sheets and Plates from Tanvir Nickel Alloys for their reliability and precision, making them the go-to choice for applications where durability, longevity, and resistance to tough environments are essential.
These Monel Sheets and Plates are primarily made up of nickel (around 67%) and copper (approximately 30%), along with trace amounts of iron, manganese, and silicon. This distinctive blend offers incredible corrosion resistance, particularly in marine and acidic settings. On the mechanical side, Monel showcases high tensile strength, toughness, and the ability to maintain its structural integrity under severe temperatures and stress. Plus, these sheets and plates can be easily fabricated, welded, and shaped without losing their mechanical properties, making them adaptable for a wide range of engineering and industrial uses.
Specifications :ASTM B127, ASME SB127, AMS 4544, QQ-N-281, DIN 17750, BS 3072NA1, BS 3076NA13
Standards : ASTM, ASME and API
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Thickness : 0.1mm to 12 mm Thk
Length : 12500 mm
Form : Coils, Foils, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) & Angle, Channel, Tray Etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Plate, Sheet, and Strip : BS3072NA18 (Sheet and Plate), BS3073NA18 (Strip), QQ-N-286 (Plate, Sheet and Strip), DIN 17750 (Plate, Sheet and Strip), ISO 6208 (Plate, Sheet and Strip)
Grade : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
| Monel K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.010 max |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Sheet and Plates in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Sheets and Plates find their place in chemical processing equipment, marine engineering, and aerospace components, thanks to their superb resistance to corrosion from saltwater and chemicals. They’re perfect for crafting valves, pumps, heat exchangers, and piping systems that face harsh environments. Moreover, their impressive strength and durability make them ideal for structural applications, fasteners, and architectural projects that demand long-lasting performance. Monel Sheets and Plates are also utilized in the oil and gas sector, desalination plants, and marine hardware, ensuring reliability and safety in critical applications where traditional metals might not hold up.
