Maraging 250/300/350 Sheets and plates Manufacturer in Cairo, Egypt

Home > Maraging 250/300/350 Sheets and plates

Tanvir Nickel Alloys is a leading manufacturer and supplier of high-quality nickel alloys and maraging steel products in Cairo, Egypt. Specializing in Maraging Steel 250, 300, and 350 sheets and plates, we offer precision-engineered materials designed for demanding industrial applications. With a commitment to excellence, we provide reliable, durable, and cost-effective solutions for industries requiring top-grade metals. Our products are crafted to meet the highest standards of performance, ensuring customer satisfaction and long-lasting results.

Vascomax 250 Sheets Egypt, Maraging 300 Sheets Cairo, Maraging Steel 350 Sheets and Plates Giza, Vascomax 250 Sheets Port Said, Maraging Steel 300 Plates Cairo, Maraging 350 Sheets Port Said, Vascomax 250 Plates Alexandria, Maraging Steel 300 Sheet Egypt, UNS-K92890 Sheets Cairo, Maraging Steel 250, 300, 350 Sheets Cairo, Egypt.

Tanvir Nickel Alloys, based in Cairo, Egypt, specializes in crafting top-notch sheets and plates made from Maraging 250, 300, and 350 grades. These high-performance steel products are designed to deliver exceptional strength, impressive toughness, and remarkable dimensional stability. The manufacturing process involves advanced techniques like vacuum induction melting (VIM) and vacuum arc remelting (VAR), followed by meticulous heat treatments—solution annealing and aging—to achieve ultra-high strength while ensuring good formability in the pre-aged state. With rigorous quality controls in place, including surface finish and flatness tolerances, Tanvir Nickel Alloys provides materials that meet the demanding standards of aerospace, defense, and high-prestige industrial applications.

Maraging 250/300/350 Sheets and plates Specifications

Specification :	ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101
Standard :	AMS, AMS, API
Size :	20mm x 1200 x 500
Specialize sheets :	Shim, Perforated Sheet, B. Q. Profile.
Finish :	Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated)
Hardness :	Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc.
Grade :	Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000)

Maraging 250/300/350 Sheets and plates Chemical Composition

Weight%

C250

17.0 / 19.0

7.0 / 8.5

0.10 max

0.03 max

0.05 / 0.15

4.6 / 5.2

0.010 max

0.3 / 0.5

Bal

0.50

Weight%	C	Si	Mn	S	P	Co	Ni	Mo	Ti	Al	Fe
Maraging 300	0.03 max	0.10 max	0.10 max	0.010 max	0.010 max	8.0-9.5	18.0-19.0	4.6-5.2	0.55-0.80	0.05-0.15	Bal

Weight%

Maraging 350

18.50

12.0

0.10 max

0.03 max

0.003

0.01 max

0.10

4.8

1.40

0.01

Maraging 250/300/350 Sheets and plates Mechanical Properties

Material	Condition	Ultimate Tensile (min)		Yield Strength (Min)		Elongation in 4D % (min)	Hardness
		Mpa	Ksi	Mpa	Ksi
Alloy Maraging C250	After Maraging heat treatment 900°F	1758	255	1724	250	6	≥ 48 HRC

Material	0.2 % Yield Strength ksi	Ultimate Tensile Strength ksi	Elongation in 4D(%)	Reduction of Area %	Hardness Rc
Maraging 300, Solution Annealed 1500° F (816°C), 1hr, AC	120	150	16	70	30
Solution Annealed Plus Aged 900 ° F (482°C), 3 hrs AC	280	290	8	40	52

Material	0.2 % Yield Strength ksi	Ultimate Tensile Strength ksi	Elongation in 4D(%)
Maraging 350	330	350	8

Maraging 250 Sheets in Cairo, Maraging Steel 300 CR Sheets Egypt, Vascomax 350 HR Sheets Exporter Giza, Maraging 250 Sheets Port Said, Maraging Steel 300 Cold Rolled Sheet Cairo, Vascomax 250 Sheets Alexandria, Maraging K93120 Plates Port Said, Vascomax 350 Hot Rolled Sheets Cairo, Maraging 250/300/350 Sheet Supplier Cairo, Egypt.

ISO Certified

Largest Inventory

On Time Deliveries

Customer Support

Largest Manufacturer and Supplier of Maraging 250/300/350 Sheets and plates in Cairo, Egypt

The Maraging steel (grades 250, 300, 350) offered by Tanvir Nickel Alloys is a low-carbon alloy that combines nickel, cobalt, and molybdenum, along with alloying elements like titanium and trace amounts of aluminum. For instance, Maraging 250 typically contains around 17-19% nickel, 7-8.5% cobalt, 4.6-5.2% molybdenum, 0.30-0.50% titanium, and no more than 0.03% carbon. When aged, these materials can achieve tensile strengths of approximately 1,700-1,800 MPa or even higher (about 240-260 ksi), depending on the specific grade and processing methods. While yield strength is notably high, ductility (elongation) does decrease somewhat, usually falling within the 6-12% range after aging. Additionally, the material showcases good toughness and resistance to crack propagation.

Types of Maraging 250/300/350 Sheets and plates

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Vascomax 250 Sheets Egypt, Maraging 300 Sheets Cairo, Maraging Steel 350 Sheets and Plates Giza, Vascomax 250 Sheets Port Said, Maraging Steel 300 Plates Cairo, Maraging 350 Sheets Port Said, Vascomax 250 Plates Alexandria, Maraging Steel 300 Sheet Egypt, UNS-K92890 Sheets Cairo, Maraging Steel 250, 300, 350 Sheets Cairo, Egypt.

Maraging 250/300/350 Sheets and plates Uses

The Maraging 250/300/350 sheets and plates from Tanvir Nickel Alloys are ideal for applications that require both exceptional strength and dependable performance under stress. They are commonly used in aerospace structural components (like landing gear and missile/rocket motor casings), high-strength tooling (such as die cast dies and extrusion tooling), precision parts, high-performance shafts and gears, and other critical components in demanding environments.
