Tanvir Nickel Alloys, located in Cairo, Egypt, stands out as a leading manufacturer and supplier of high-performance Inconel 625 Stud Bolts. They specialize in delivering precision-engineered solutions tailored for demanding industrial settings. With a strong focus on quality and innovation, this company ensures that its products adhere to strict international standards. The Inconel 625 Stud Bolts from Tanvir Nickel Alloys are known for their exceptional corrosion resistance, impressive strength, and remarkable durability, making them perfect for high-temperature and chemically aggressive environments. Committed to customer satisfaction, timely deliveries, and technical expertise, Tanvir Nickel Alloys has built a reputation as a reliable partner for industries that need trustworthy and long-lasting fasteners.
These Inconel 625 Stud Bolts are primarily made up of nickel (at least 58%), chromium (20–23%), and molybdenum (8–10%), along with trace amounts of iron, niobium, and tantalum. This alloy boasts outstanding mechanical properties, including high tensile strength, excellent fatigue resistance, and superior toughness across a broad temperature range. Its remarkable corrosion resistance safeguards against both oxidizing and reducing environments, especially in marine and chemical applications. The alloy remains stable at elevated temperatures up to 980°C, ensuring dependable performance in critical industrial sectors like power generation, petrochemical, and aerospace.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Stud Bolts find extensive use in industries where extreme corrosion resistance and mechanical strength are crucial. They are particularly suited for chemical processing plants, petrochemical refineries, and marine environments, where exposure to acids, salts, and high temperatures is routine. These bolts are utilized in high-pressure vessels, heat exchangers, turbines, and exhaust systems, providing secure and durable connections. Moreover, they play a vital role in aerospace and power generation applications, where maintaining structural integrity during thermal cycling is essential. Their durability and resistance to harsh conditions make them a top choice for demanding applications.
