Tanvir Nickel Alloys stands out as a top-notch manufacturer and supplier located in Cairo, Egypt, specializing in high-quality Inconel 600 Stud Bolts that excel in extreme conditions. These stud bolts are celebrated for their remarkable strength, durability, and resistance to corrosion, all while adhering to international standards for high-temperature and high-pressure applications. With a commitment to precision manufacturing and strict quality control, Tanvir Nickel Alloys delivers Inconel 600 Stud Bolts that industries like chemical processing, power generation, and marine engineering can trust for long-lasting fastening solutions.
The composition of Inconel 600 Stud Bolts includes about 72% nickel, 14–17% chromium, and 6–10% iron, along with small amounts of manganese, silicon, and copper. This distinctive blend grants them exceptional resistance to oxidation, carburization, and chloride-ion stress-corrosion cracking. On the mechanical side, they boast a tensile strength of roughly 655 MPa, a yield strength of 310 MPa, and an elongation of around 40%. Even under intense thermal and mechanical stresses, this alloy maintains impressive strength, toughness, and dimensional stability.
| Specifications | ASTM A166 / ASME A166 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Length | 3 mm – 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Treatment | Passivation /plain |
| Others Factor | OEM, ODM, ±0.03MM tolerance |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Packing | IN BULK: carton, pallet, Small Boxes or customer request |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Stud Bolts in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Stud Bolts are extensively utilized in sectors that require high heat and corrosion resistance. They’re commonly found in chemical plants, heat exchangers, boilers, pressure vessels, and nuclear reactors. In the aerospace and marine industries, these bolts are perfect for securing components that face high temperatures and corrosive environments. They also play a vital role in gas turbines, furnace fixtures, and power generation systems. The blend of strength, oxidation resistance, and durability makes Inconel 600 Stud Bolts the go-to fastening solution for critical and high-performance industrial applications.
