Tanvir Nickel Alloys, located in Cairo, Egypt, specializes in high-quality Copper Nickel 90/10 fittings, designed to deliver exceptional performance and longevity. Comprising 90% copper and 10% nickel, these fittings are perfect for marine and industrial applications due to their excellent corrosion resistance and durability. Our fittings are manufactured to meet rigorous standards, ensuring reliable and efficient solutions for various piping needs in challenging environments. Trust Tanvir Nickel Alloys for superior quality and performance.
Copper Nickel 90/10 fittings are 90% copper and 10% nickel, with trace elements of iron and manganese. This product boasts excellent corrosion resistance, especially in marine environments, thanks to its resistance to seawater. It also exhibits good mechanical properties, including high tensile strength (about 310 MPa) and good ductility. The resistance to biofouling and durability of this compound under high pressure conditions make it ideal for marine and industrial applications. Its high thermal conductivity ensures smooth thermal conductivity in systems.
| Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Bending Radius | Radius=1 D, 2D, 3 D, 5D, 6D, 8 D, 10D |
| Grade | 90/10 |
| Size Range | Seamless Butt-Weld Fitting: From 1/2″ – 10″ Welded ButtWeld Fitting: From 1/2″ – 48″ |
| Dimension | ASME/ ANSI B16.9 | ASME B16.28 | MSS-SP-43 | BS1560 | BS4504 | BS10 |
| Size Ranges | ½” NB to 24″ NB in Schedule 10s, 40s, 80s, 160s, XXS. |
| Types | Welded | Seamless | Fabricated |
| Process of Manufacturing | Push, Press, Cast, Forge. |
| Thickness of Fitting | SCH10, SCH 20, SCH30, STD SCH40, SCH80, SCH60, XS, SCH100, SCH 120, SCH140, SCH 160, XXS available with NACE MR 01-75 |
| Grade | Fe | Ni | Cu | Pb | Mn | Zn |
| Cu-Ni 90-10 | 1.8 max | 9-11 max | 88.6 min | .05 max | 1.0 max | 1 max |
| Element | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Copper Nickel 90/10 | 2260 F | 0.323 lb/in3 at 68 F | 20000 psi | 50000 psi | 30 % |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Fittings in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper nickel 90/10 fittings are widely used in marine engineering due to their excellent corrosion resistance in seawater and other harsh environments They are commonly used in ships for piping systems, heat exchangers and cooling system. Additionally, they are used in coastal areas, desalination plants and pharmaceutical plants. Its resistance to biofouling and high durability make it suitable for use where salt water and high pressure inputs are common.
