Tanvir Nickel Alloys stands out as a top-notch manufacturer and supplier of Alloy C263 Foil in Cairo, Egypt. They’re renowned for crafting high-quality nickel-based superalloys that excel in extreme conditions. The Alloy C263 Foil is designed to deliver remarkable strength, oxidation resistance, and formability even at elevated temperatures. With cutting-edge facilities and rigorous quality standards, Tanvir Nickel Alloys guarantees exceptional precision and durability in every product they offer. This Alloy C263 Foil is crucial for industries like aerospace, gas turbine, petrochemical, and power generation, where high-performance materials are vital for demanding thermal and mechanical applications.
Alloy C263 Foil is a unique blend of nickel, cobalt, chromium, and molybdenum, containing about 50–55% nickel, 19–21% chromium, 19–21% cobalt, 5.6–6.1% molybdenum, along with trace amounts of titanium and aluminum. This special composition gives it outstanding high-temperature strength, corrosion resistance, and weldability. The alloy boasts a tensile strength of around 1000 MPa and maintains impressive creep and rupture resistance up to 800°C. Additionally, it offers good ductility, oxidation resistance, and thermal stability, making it perfect for both high-stress and oxidizing environments.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Foil in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Foil is extensively utilized in applications that require high strength and oxidation resistance at elevated temperatures. It’s particularly well-suited for manufacturing components in gas turbines, combustion liners, transition ducts, and heat shields within the aerospace and power generation sectors. In the chemical and petrochemical industries, it finds its place in reactor linings, heat exchangers, and furnace parts that face corrosive conditions. Its excellent formability also makes it ideal for precision parts in high-temperature equipment. Alloy C263 Foil is highly regarded for its reliability, durability, and performance in challenging environments.
